Operate at a fraction of the cost
No Glare - No Shadows
Full Spectrum, Daylight Quality Light
Instant On at 0 degrees F
All Fixtures Available in 120 or 277 volts
|
|
|
 |
|
|
AG 9000
-
Replaces
8 foot 2 Lamp Fixtures
-
Enclosed
and Gasketed
-
Low
Temperature Start Electronic Ballast
Uses
84 Watts, produces equivalent of 700 incandescent watts
Minimum
to Medium Light
Mounting
Height, 12' - 14'
AG 9000 HL
-
Enclosed
and Gasketed
-
Low
Temperature Start, High Output Ballast
Uses
84 Watts, produces equivalent of 800 incandescent watts
Medium
Light
Mounting
Height, 14' - 16'
Fixtures also available open with reflector
|
|
|
|
A Superior Alternative to Metal Halides

48.5" (L) x 17.5" (W) x 5.75
(H)
4EN6
|
-
Replaces 465 Watt Metal Halides
-
Open
or Enclosed 4 foot, 6 Lamp Fixture
-
Utilizes two
Low Temperature Start, High Output Electronic Ballasts
-
Patented Specular Reflector
-
Uses
221 Watts, Produces 30% More Light than a 465 Watt Metal Halide
-
Mounting
Height, 18' - 26'
-
Fixtures available to replace 250 & 1000 watt metal halides
|
|

Orion 4EN6 Fluorescent vs. Metal Halide
General
Information:
Orion high output, full spectrum, cold temperature start
fluorescents provide several advantages over comparable metal halides.
Orion
Fluorescents:
-
Operate
on 1/2 the electricity
-
Produce
30% - 50% more light
-
Last
50% longer
-
Produce
NO glare or shadows
-
Are
instant on, no delay
-
Produce
daylight quality light
-
Provide
better light distribution
-
Duel
switching allows for multiple light levels
-
Easy
installation, weighs only 17 lbs.
-
UL
Listed
|
| |
Orion High
Performance T8
Fluorescent 4R6 |
Comparable
Metal Halide |
| Light Output @ 18' |
45 Foot
Candles |
35 Foot
Candles |
| AMP Draw |
1.84
amp 120 volt
083 amp 277 volt |
3.87
amp 120 volt
1.68 amp 277 volt |
| Watts Consumed |
221 |
465 |
| Lumen Loss Over Life |
7% |
40% |
| Lamp Life |
20,000
- 30,000 hrs. |
10,000
- 20,000 hrs. |
| Warranty |
5 yr.
Ballast
30 mo. Lamp |
3 yr.
Ballast
0 - 1 yr. Lamp |
| Replacement Lamp Cost |
$24.00 |
$36.00 |
|
|
